17-39
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Chapter 17 Node Reference
17.3.2 View and Provision ANS Parameters
Table 17-5 shows the following information for all ONS 15454 ANS parameters:
• Min—Minimum value in decibels.
• Max—Maximum value in decibels.
• Def—Default value in decibels. Other defaults include MC (metro core), CG (control gain),
U (unknown).
• Group—Group(s) to which the parameter belongs: ES (east side), WS (west side), Rx (receive),
Tx (transmit), Amp (amplifier), P (power), DB (drop band), DC (drop channel), A (attenuation),
Th (threshold).
• Network Type—Parameter network type: MC (metro core), MA (metro access), ND (not DWDM)
• Optical Type—Parameter optical type: TS (32 channel terminal), FC (flexible channel count
terminal), O (OADM), H (hub), LS (line amplifier), R (ROADM), U (unknown)
ROADM Network Network Type
Span Loss East and West Expected Span Loss
Amplifier Tx East and West Side Transmit Amplifier Working Mode
East and West Side Transmit Amplifier Channel Power
East and West Side Transmit Amplifier Gain
East and West Side Transmit Amplifier Tilt
Amplifier Rx East and West Side Receive Amplifier Working Mode
East and West Side Receive Amplifier Channel Power
East and West Side Receive Amplifier Gain
East and West Side Receive Amplifier Tilt
Thresholds Tx East and West Side Fiber Stage Input Threshold
Thresholds Rx East and West Side Osc Los Threshold
East and West Side Channel Los Threshold
East and West Side Receive Amplifier Input Power Fail
Power East and West Side Add and Drop Input Power (if 32DMX
East/West is installed)
East and West Side Add and Drop Output Power
East and West Side Add and Drop Drop Power (if 32DMX
East/West is installed)
East and West Side Channel (n) Drop Power (if 32DMX-O
East/West is installed)
Table 17-4 ANS Parameters By Node Type (continued)
Node Type Parameter Group Parameters
Table 17-5 ANS Parameters Summary
General Name Min Max Def Group Network Type Optical Type
Network Type – – MC Root MC, MA, ND U, TS, FC, O, H, LS, R
West Side Rx Max Expected Span Loss 0 60 60 WS, Rx MC, MA TS, FC, O, H, LS, R
