3-31
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 3 Turn Up a Node
DLP-G287 Add a TARP Manual Adjacency Table Entry
DLP-G287 Add a TARP Manual Adjacency Table Entry
Step 1 In node view, click the Provisioning > OSI > TARP > MAT tabs.
Step 2 Click Add.
Step 3 In the Add TARP Manual Adjacency Table Entry dialog box, enter the following:
• Level—Sets the TARP Type Code that will be sent:
–
Level 1—Indicates that the adjacency is within the same area as the current node. The entry
generates Type 1 PDUs.
–
Level 2—Indicates that the adjacency is in a different area than the current node. The entry
generates Type 2 PDUs.
• NSAP—Enter the OSI NSAP address in the NSAP field or, if preferred, click Use Mask and enter
the address in the Masked NSAP Entry dialog box.
Step 4 Click OK to close the Masked NSAP Entry dialog box, if used, and then click OK to close the Add Static
Entry dialog box.
Step 5 Return to your originating procedure (NTP).
DLP-G288 Provision OSI Routers
Note Router 1 must be enabled before you can enable and edit the primary manual area addresses for
Routers 2 and 3.
Purpose This task adds an entry to the TARP manual adjacency table (MAT).
Entries are added to the MAT when the ONS 15454 must communicate
across routers or NEs that lack TARP capability.
Tools/Equipment None
Prerequisite procedures DLP-G46 Log into CTC, page 2-25
Required/As needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Purpose This task enables an OSI router and edits its primary manual area address.
Tools/Equipment None
Prerequisite Procedures NTP-G22 Verify Common Card Installation, page 3-4
DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
