DLP-G306 Provision the TXP_MR_2.5G and TXPP_MR_2.5G Cards Client Port Alarm and TCA Thresholds
Step 4 Click Apply.
Step 5 Under Types, click the Alarm radio button and click Refresh.
Step 6 Referring to Table 5-36, provision the Alarm thresholds for RX Power High, RX Power Low, TX Power
High, and TX Power Low based on the client interface that is provisioned.
Note You must modify 15 Min and 1 Day independently. To do so, choose the appropriate radio button
and click Refresh.
ETR_CLO 15454-SFP-200
15454E-SFP-200
–17 0 –16 3
ISC compat 15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–20 –3 –16 3
ISC peer 15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–20 –3 –16 3
Table 5-35 TXP_MR_2.5G and TXPP_MR_2.5G Card Client Interface TCA Thresholds (continued)
Port Type
(by CTC)
Pluggable Port Module
(SFP or XFP)
TCA RX
Power Low
TCA RX
Power High
TCA TX
Power Low
TCA TX
Power High
Table 5-36 TXP_MR_2.5G and TXPP_MR_2.5G Card Client Interface Alarm Thresholds
Port Type
(by CTC)
Pluggable Port Module
(SFP)
Alarm RX
Power Low
Alarm RX
Power High
Alarm TX
Power Low
Alarm TX
Power High
OC-3 15454-SFP3-1-IR –26 –5 –18 –5
STM-1 15454E-SFP-L.1.1 –27 –7 –18 –5
OC-12 15454-SFP12-4-IR –31 –4 –18 –5
STM-4 15454E-SFP-L.4.1 –31 –5 –18 –5
OC-48 ONS-SE-2G-S1 –21 0 –13 0
15454-SFP-OC48-IR –21 3 –8 3
STM-16 ONS-SE-2G-S1 –21 0 –13 0
15454E-SFP-L.16.1 –21 3 –8 3
ONE_GE 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–20 3 –13 –1
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–23 0 –13 0
ESCON 15454-SFP-200
15454E-SFP-200
–24 –11 –32 –11
DV6000 15454-SFP-OC48-IR –31 –4 –18 –5
15454E-SFP-L.16.1 –21 3 –8 3
SDI_D1_
VIDEO
15454-SFP12-4-IR –31 –4 –18 –5
15454E-SFP-L.4.1 –31 –5 –18 –5
HDTV 15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–23 0 –13 0
