A.3 Equipment Inventory
A.3 Equipment Inventory
In node view, the Inventory tab displays information about the ONS 15454 equipment, including:
• Location—Identifies where the equipment is installed, either chassis or slot number.
• Eqpt Type—Displays the type of equipment but not the specific card name, for example, OC-12 or
DS-1.
• Actual Eqpt Type—Displays the specific card name, for example, OC12 IR/STM4 SH 1310.
• Admin State—Changes the card service state unless network conditions prevent the change. For
more information about card administrative states, see Appendix C, “DWDM Administrative and
Service States.”
– IS (ANSI) or Unlocked (ETSI)—Places the card in the In-Service and Normal (IS-NR [ANSI])
or Unlocked-enabled (ETSI) service state.
– OOS,MA (ANSI) or Locked,maintenance (ETSI)—Places the card in the Out-of-Service and
Autonomous, Maintenance (OOS-AU,MT [ANSI]) or Unlocked-disabled,maintenance (ETSI)
service state.
• Service State—Displays the current card service state, which is an autonomously generated state
that gives the overall condition of the card. Service states appear in the format: Primary
State-Primary State Qualifier, Secondary State. For more information about card service states, see
Appendix C, “DWDM Administrative and Service States.”
• HW Part #—Displays the hardware part number; this number is printed on the top of the card or
equipment piece.
• HW Rev—Displays the hardware revision number.
• Serial #—Displays the equipment serial number; this number is unique to each card.
• CLEI Code—Displays the Common Language Equipment Identifier code.
• Firmware Rev—Displays the revision number of the software used by the application-specific
integrated circuit (ASIC) chip installed on the ONS 15454 card.
• Product ID—Displays the manufacturing product identifier for a hardware component, such as a fan
tray, chassis, or card. The Product ID column displays “N/A” for equipment existing before
Software Release 4.6.
• Version ID—Displays the manufacturing version identifier for a fan tray, chassis, or card. The
Version ID column displays “N/A” for equipment existing before Software Release 4.6.
Buttons at the bottom of the Inventory tab are used to delete or reset a card when a card is selected, or
to delete a PPM if a PPM is selected on the table.
Sort table (secondary
sorting keys)
Press the Shift key and
simultaneously click the column
header.
Choose Sort Column (incremental).
Reset sorting — Choose Reset Sorting.
View table row count — View the number after “Row count=” (it is
the last item on the shortcut menu).
Table A-7 Table Display Options (continued)
Task Click Right-Click Shortcut Menu
