Appendix B Hardware Specifications
B.2.1 Power
B.2.1 Power
Table B-1 provides power consumption information for the ONS 15454 cards.
Table B-1 Individual Card Power Requirements
Card Type Card Name Watts Amperes at –48 V BTU/Hr.
Common Control
Cards
TCC2/TCC2P 19.20 0.4 66.8
AIC-I 4.8 0.1 15.3
AEP 3 (from +5 VDC
from AIC-I)
10.2
MIC-A/P 0.13 via TCC2/TCC2P —
MIC-C/T/P 0.38 via TCC2/TCC2P —
DWDM Cards
OSCM Nominal 23
Maximum 26
Nominal 0.48
Maximum 0.54
Nominal 78.48
Maximum 88.71
OSC-CSM Nominal 24
Maximum 27
Nominal 0.5
Maximum 0.56
Nominal 81.89
Maximum 92.12
OPT-PRE Minimum 25
Nominal 30
Maximum39
Minimum 0.52
Nominal 0.5
Maximum 0.81
Minimum 85.3
Nominal 102.36
Maximum 88.71
OPT-BST Nominal 30
Maximum 39
Nominal 0.63
Maximum 0.81
Nominal 102.36
Maximum 88.71
OPT-BST-E Nominal 30
Maximum 39
Nominal 0.63
Maximum 0.81
Nominal 102.36
Maximum 88.71
32MUX-O Nominal 16
Maximum 25
Nominal 0.33
Maximum 0.52
Nominal 54.59
Maximum 85.3
32DMX-O Nominal 16
Maximum 25
Nominal 0.33
Maximum 0.52
Nominal 54.59
Maximum 85.3
32DMX Nominal 15
Maximum 25
Nominal 0.31
Maximum 0.52
Nominal 51.21
Maximum 85
4MD-xx.x Nominal 17
Maximum 25
Nominal 0.35
Maximum 0.52
Nominal 58.0
Maximum 85.3
AD-1C-xx.x Nominal 17
Maximum 25
Nominal 0.35
Maximum 0.52
Nominal 58.0
Maximum 85.3
AD-2C-xx.x Nominal 17
Maximum 25
Nominal 0.35
Maximum 0.52
Nominal 58.0
Maximum 85.3
AD-4C-xx.x Nominal 17
Maximum 25
Nominal 0.35
Maximum 0.52
Nominal 58.0
Maximum 85.3
