Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
December 2006
Appendix B Hardware Specifications
B.5 Transponder and Muxponder Card Specifications
The 32WSS card has the following additional specifications:
• Environmental
–
Operating temperature:
C-Temp: –5 to +55 degrees Celsius (+23 to +131 degrees Fahrenheit)
–
Operating humidity: 5 to 95 percent RH
• Dimensions
–
Height: 12.65 in. (321.3 mm)
–
Width: 1.84 in. (46.8 mm)
–
Depth: 9.00 in. (228.6 mm)
B.5 Transponder and Muxponder Card Specifications
This section provides specifications for the TXP_MR_10G, MXP_2.5G_10G, TXP_MR_2.5G,
TXPP_MR_2.5G, MXP_MR_2.5G, MXPP_MR_2.5G, MXP_2.5G_10E, and TXP_MR_2.5G cards.
13 4 42.1 194.4 1542.14
14 42.9 194.3 1542.94
15 43.7 194.2 1543.73
16 44.5 194.1 1544.53
17 5 46.1 193.9 1546.12
18 46.9 193.8 1546.92
19 47.7 193.7 1547.72
20 48.5 193.6 1548.51
21 6 50.1 193.4 1550.12
22 50.9 193.3 1550.92
23 51.7 193.2 1551.72
24 52.5 193.1 1552.52
25 7 54.1 192.9 1554.13
26 54.9 192.8 1554.94
27 55.7 192.7 1555.75
28 56.5 192.6 1556.55
29 8 58.1 192.4 1558.17
30 58.9 192.3 1558.98
31 59.7 192.2 1559.79
32 60.6 192.1 1560.61
Table B-18 32WSS Channel Plan (continued)
Channel
Number Band Channel ID Frequency (GHz) Wavelength (nm)
