Appendix B Hardware Specifications
B.4.12 AD-4C-xx.x Card Specifications
AD-2C-xx.x optical input and output power varies with amplifier output levels and the class of
transponder interfaces used. See Table 16-3 on page 16-6 through Table 16-5 on page 16-8 for this
information.
The AD-2C-xx.x has the following additional specifications:
• Environmental
– Operating temperature:
C-Temp: –5 to +55 degrees Celsius (+23 to +131 degrees Fahrenheit)
– Operating humidity: Telcordia GR-63 5.1.1.3 compliant; 5 to 95 percent RH
• Dimensions
– Height: 12.650 in. (321.3 mm)
– Width: 0.92 in. (23.4 mm)
– Depth: 9.0 in. (228.6 mm)
B.4.12 AD-4C-xx.x Card Specifications
Table B-10 lists the AD-4C-xx.x optical specifications.
Table B-9 AD-2C-xx.x Card Optical Specifications
Parameter Note Condition Min Max Unit
Trx filter shape
(–0.5 dB bandwidth)
TrxBW
2
All SOP and within whole
operating temperature range
COM Rx—xx.xx Tx
COM Rx—yy.yy Tx
+/–180 — pm
xx.xx Rx—COM Tx
yy.yy Rx—COM Tx
+/–180 —
Rfx filter shape
(–0.5 dB bandwidth)
RfxBW
2
All SOP and within whole
operating temperature range
COM Rx—Exp Tx
Exp Rx—COM Tx
+/–180 — pm
Insertion loss
(drop section)
All SOP and within whole
operating temperature range
(two connectors included)
COM Rx—xx.xx Tx — 2.0 dB
COM Rx—yy.yy Tx — 2.4 dB
Insertion loss
(express section)
VOA at minimum attenuation;
all SOP and within whole
operating temperature range
(two connectors included)
COM Rx—Exp Tx — 2.7 dB
Exp Rx—COM Tx — 1.6 dB
Insertion loss
(add section)
VOA at minimum attenuation;
all SOP and within whole
operating temperature range
(two connectors included)
xx.xx Rx—COM Tx — 3.1 dB
yy.yy Rx—COM Tx — 2.7 dB
VOA dynamic range — — 30 — dB
Maximum optical
input power
— — 300 — mW
