19-8
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Chapter 19 CTC Operation Reference
19.5.1 Node View
On the ONS 15454 ETSI, the colors of the Front Mount Electrical Connection (FMEC) cards reflect the
real-time status of the physical FMEC cards. Table 19-5 lists the FMEC card colors. The FMEC ports
shown in CTC do not change color.
Note You cannot preprovision FMECs.
The wording on a card in node view shows the status of a card (Active, Standby, Loading, or
Not Provisioned). Table 19-6 lists the card statuses.
Port color in both card and node view indicates the port service state. Table 19-7 lists the port colors and
their service states. For more information about port service states, refer to Appendix C, “DWDM
Administrative and Service States.”
White Slot is provisioned; a functioning card is installed.
Yellow Slot is provisioned; a Minor alarm condition exists.
Orange Slot is provisioned; a Major alarm condition exists.
Red Slot is provisioned; a Critical alarm exists.
Table 19-4 Node View Card Colors (continued)
Card Color Status
Table 19-5 Node View FMEC Color
Upper Shelf FMEC Color Status
White Functioning card is installed.
Yellow Minor alarm condition exists.
Orange (Amber) Major alarm condition exists.
Red Critical alarm exists.
Table 19-6 Node View Card Statuses
Card Status Description
Sty Card is in standby mode.
Act Card is active.
NP Card is not present.
Ldg Card is resetting.
