Appendix A CTC Information and Shortcuts
A.2.5 Table Display Options
A.2.5 Table Display Options
Right-clicking a table column displays a menu. Table A-7 shows table display options, which include
rearranging or hiding CTC table columns and sorting table columns by primary or secondary keys.
Update circuits with
new node
Right-click a node and choose Update Circuits With New Node from the
shortcut menu. Use this command when you add a new node and want to pass
circuits through it.
Display a link end
point
Right-click a span. From the shortcut menu, choose Go To {<node> | <port>
| <slot>} for the drop port you want to view. CTC displays the card in card
view.
Display span
properties
Do any of the following:
• Move the mouse over a span; the properties appear near the span.
• Click a span; the properties appear in the upper left corner of the window.
• Right-click a span; the properties appear at the top of the shortcut menu.
Perform a path
protection (ANSI) or
SNCP (ETSI)
protection switch for
an entire span
Right-click a network span and click Circuits. In the Circuits on Span dialog
box, switch options appear in the path protection (or SNCP) Span Switching
field.
Display DWDM span
properties
Right-click a DWDM network span and choose Circuits from the shortcut
menu. The optical channel network connection (OCHNC), optical direction,
and circuit appear.
Upgrade a span Right-click a span and choose Upgrade Span from the shortcut menu. Not
applicable to DWDM nodes.
Table A-6 Network Management Tasks in Network View (continued)
Action Task
Ta b l e A - 7 Ta b l e D i s p l a y O p t i o n s
Task Click Right-Click Shortcut Menu
Resize column Click while dragging the column
separator to the right or left.
—
Rearrange column order Click while dragging the column
header to the right or left.
—
Reset column order — Choose Reset Columns Order/Visibility.
Hide column — Choose Hide Column.
Show column — Choose Show Column > column_name.
Display all hidden
columns
— Choose Reset Columns Order/Visibility.
Sort table (primary) Click a column header; each
click changes sort order
(ascending or descending).
Choose Sort Column.
