Appendix B Hardware Specifications
B.4.6 32MUX-O Card Specifications
B.4.6 32MUX-O Card Specifications
The 32 MUX-O card optical specifications are listed in Table B-3.
Note For power specifications, refer to the “16.1.7 Multiplexer, Demultiplexer, and OADM Card Interface
Classes” section on page 16-6.
The 32MUX-O card has the following additional specifications:
• Environmental
– Operating temperature:
C-Temp: –5 to +55 degrees Celsius (+23 to +131 degrees Fahrenheit)
– Operating humidity: 5 to 95 percent relative humidity (RH)
• Dimensions
– Height: 12.65 in. (321.3 mm)
– Width: 1.84 in. (46.8 mm)
– Depth: 9.00 in. (228.6 mm)
B.4.7 32DMX-O Card Specifications
The 32DMX-O card optical specifications are listed in Table B-4.
Note For power specifications, see the “16.1.7 Multiplexer, Demultiplexer, and OADM Card Interface
Classes” section on page 16-6.
Table B-3 32MUX-O Optical Specifications
Parameter Note Condition Min Max Unit
Tx filter shape (–1 dB
bandwidth)
All standard operating
procedures (SOP) and
within whole operating
temperature range
In 1/32—Out beginning
of life (BOL)
+/–180 +/–300 pm
In 1/32—Out end of life
(EOL)
+/–160 +/–300 pm
Insertion loss All SOP and within
whole operating
temperature range
In 1/32—Out BOL 4 8.0 dB
In 1/32—Out EOL 4 8.5 dB
VOA dynamic range — — 25 — dB
Optical monitor
tap-splitting ratio on
monitor port
Optical monitor port
with respect to output
port in multiplexer
only
—1921dB
Maximum optical
input power
— — 300 — mW
