Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 5 Provision Transponder and Muxponder Cards
DLP-G232 Change TXP_MR_2.5G and TXPP_MR_2.5G Cards Line Threshold Settings for SONET or SDH Payloads
Step 4 Click Apply.
Step 5 Return to your originating procedure (NTP).
DLP-G232 Change TXP_MR_2.5G and TXPP_MR_2.5G Cards Line Threshold
Settings for SONET or SDH Payloads
Step 1 In node view, double-click the TXP_MR_2.5G or TXPP_MR_2.5G card where you want to change the
line threshold settings.
Step 2 Click the Provisioning > Line Thresholds tabs.
Note You must modify Near End, and Far End independently; 15 Min and 1 Day independently; and
Line and Section independently. To do so, choose the appropriate radio button and click Refresh.
Step 3 Modify any of the settings in Table 5-32.
Expected Displays the current expected string; sets
a new expected string. You can click the
button on the right to change the display.
Its title changes, based on the current
display mode. Click Hex to change the
display to hexadecimal (button changes to
ASCII); click ASCII to change the
display to ASCII (button changes to Hex).
String of trace string size
Received (Display only) Displays the current
received string. You can click Refresh to
manually refresh this display, or check
the Auto-refresh every 5 sec check box to
keep this display updated automatically.
String of trace string size
Purpose This task changes the line threshold settings for TXP_MR_2.5G and
TXPP_MR_2.5G transponder cards carrying OC-3/STM-1,
OC-12/STM-4, and OC-48/STM-16 payloads.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Table 5-31 TXP_MR_2.5G and TXPP_MR_2.5G Transponder Card Section Trace Settings
Parameter Description Options
