NTP-G11 Install an External Wire-Wrap Panel on the AEP (ANSI Only)
Wrap the ground wire of your computer cable to pin A3 on the craft pin field. Table 1-8 shows the pin
assignments for the CRAFT pin field.
Note You cannot use the craft backplane pins and the EIA/TIA-232 port on the TCC2/TCC2P card
simultaneously. Using a combination prevents access to the node or causes a loss in connectivity.
Step 3 Return to your originating procedure (NTP).
NTP-G11 Install an External Wire-Wrap Panel on the AEP
(ANSI Only)
Step 1 Position the lower cover over the AEP. Make sure that the AEP AMP Champ connectors protrude
through the cutouts in the lower cover (Figure 1-23).
Table 1-8 Craft Interface Pin Assignments
Pin Field Contact Function
Craft A1 Receive
A2 Transmit
A3 Ground
A4 DTR
Purpose This procedure connects an external wire-wrap panel to the ONS 15454
ANSI AEP to provide the physical alarm contacts for the AEP.
Tools/Equipment External wire-wrap panel
Prerequisite Procedures NTP-G9 Install the Alarm Expansion Panel (ANSI Only), page 1-44
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
