DLP-G221 Change OTN Settings for TXP_MR_10G and TXP_MR_10E Cards
Table 5-14 describes the values on the Provisioning > OTN > FEC Thresholds tab.
Table 5-15 describes the values on the Provisioning > OTN > Trail Trace Identifier tab.
UAS Unavailable seconds Numeric. Threshold display options
include:
• Direction—Near End or Far End
• Interval—15 Min (minutes) or 1 day
• Types—SM (OTUk) or PM (ODUk)
Choose an option in each category and
click Refresh.
BBE Background block errors Numeric. Threshold display options
include:
• Direction—Near End or Far End
• Interval—15 Min (minutes) or 1 day
• Types—SM (OTUk) or PM (ODUk)
Choose an option in each category and
click Refresh.
FC Failure counter Numeric. Threshold display options
include:
• Direction—Near End or Far End
• Interval—15 Min (minutes) or 1 day
• Types—SM (OTUk) or PM (ODUk)
Choose an option in each category and
click Refresh.
Table 5-13 TXP_MR_10G and TXP_MR_10E Transponder Card ITU-T G.709 Threshold Settings
Parameter Description Options
Table 5-14 TXP_MR_10G and TXP_MR_10E Transponder Card FEC Threshold Settings
Parameter Description Options
Port (Display only) Displays the port number
and optional name.
2
Bit Errors
Corrected
Displays the number of bit errors
corrected during the selected time period.
Numeric display. Can be set for
15-minute or one-day intervals.
Uncorrectable
Words
Displays the number of uncorrectable
words in the selected time period.
Numeric display. Can be set for
15-minute or one-day intervals.
