Chapter 1      Install the Shelf and Common Control Cards
NTP-G16 Perform the Shelf Installation Acceptance Test
NTP-G16 Perform the Shelf Installation Acceptance Test
Step 1 If you installed an ONS 15454 ETSI shelf, complete Table 1-12 by verifying that each applicable
procedure was completed.
Step 2 If you installed an ONS 15454 ANSI shelf, complete Table 1-13 by verifying that each applicable
procedure was completed.
Purpose Use this procedure to perform a shelf installation acceptance test for the
ONS 15454 ETSI and ONS 15454 ANSI.
Tools/Equipment Voltmeter
Oval and/or block ferrites
Prerequisite Procedures Applicable procedures in Chapter 1, “Install the Shelf and Common
Control Cards”
Required/As Needed Required
Onsite/Remote Onsite
Security Level None
Table 1-12 ONS 15454 ETSI Shelf Installation Task Summary
Description Completed
NTP-G1 Unpack and Inspect the Shelf Assembly, page 1-6
NTP-G2 Install the Shelf Assembly, page 1-8
NTP-G3 Open and Remove the Front Door, page 1-20
NTP-G4 Open and Remove the FMEC Cover (ETSI Only), page 1-23
NTP-G6 Install the MIC-A/P and MIC-T/C/P FMECs (ETSI Only), page 1-28
NTP-G7 Install the Power and Ground, page 1-30
NTP-G8 Install the Fan-Tray Assembly, page 1-40
NTP-G10 Attach Wires to Alarm, Timing, LAN, and Craft Pin Connections, page
1-47
NTP-G12 Install and Close the FMEC Cover (ETSI Only), page 1-63
NTP-G14 Install DWDM Equipment, page 1-66
NTP-G15 Install the Common Control Cards, page 1-71
Table 1-13 ONS 15454 ANSI Shelf Installation Task Summary
Description Completed
NTP-G1 Unpack and Inspect the Shelf Assembly, page 1-6
NTP-G2 Install the Shelf Assembly, page 1-8
NTP-G3 Open and Remove the Front Door, page 1-20
NTP-G5 Remove the Backplane Covers (ANSI Only), page 1-26
NTP-G7 Install the Power and Ground, page 1-30
