Chapter 5 Provision Transponder and Muxponder Cards
DLP-G224 Change Section Trace Settings for MXP_2.5G_10G and MXP_2.5G_10E Cards
Step 4 Click Apply.
Step 5 Return to your originating procedure (NTP).
DLP-G224 Change Section Trace Settings for MXP_2.5G_10G and
MXP_2.5G_10E Cards
Note The Section Trace tab appears only if you have created a PPM for the card.
Step 6 In node view, double-click the MXP_2.5G_10G or MXP_2.5G_10E card where you want to change the
section trace settings.
SyncMsgIn Enables synchronization status messages (S1 byte),
which allow the node to choose the best timing
source. (This parameter does not appear for the
MXP_2.5G_10E trunk port.)
Checked or unchecked
Send
DoNotUse
When checked, sends a DUS message on the S1
byte. (This parameter does not appear for the
MXP_2.5G_10E trunk port.)
Checked or unchecked
Reach Displays the optical reach distance of the client
port.
• Autoprovision (default)
• I1
• S1
• S2
• L1
• L2
• L3
Wavelength Displays the wavelength of the client port.
• First Tunable Wavelength
• Further wavelengths: 1310 nm to 1550 nm
100-GHz ITU spacing, CWDM spacing
• Supported wavelengths are marked by asterisks
(**)
Purpose This task changes the section trace settings for MXP_2.5G_10G and
MXP_2.5G_10E muxponder cards.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Table 5-17 MXP_2.5G_10G or MXP_2.5G_10E Muxponder Card Line Settings (continued)
Parameter Description Options
