1-53
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Chapter 1 Install the Shelf and Common Control Cards
DLP-G23 Install Alarm Wires on the Backplane (ANSI Only)
Step 2 Return to your originating procedure (NTP).
DLP-G23 Install Alarm Wires on the Backplane (ANSI Only)
Step 1 Using 100-ohm shielded BITS clock cable pair #22 or #24 AWG (0.51 mm² or 0.64 mm²) twisted-pair
T1-type wires, wrap the alarm wires on the appropriate wire-wrap pins according to local site practice.
Ground the shield of the BITS Input cable at the BITS end. For BITS Output, wrap the ground shield of
the BITS cable to the frame ground pin (FG1) located below the column of BITS pins.
Figure 1-21 shows alarm pin assignments for the AIC-I in the Release 3.4 or higher ONS 15454
backplane, and Figure 1-22 calls out the external alarm pins on that backplane.
LAN 1
Connecting to DTE
(a PC/workstation or
router)
Straight-through Ethernet
cable
11PNMSRX+
white/green
22PNMSRX–
green
3 3 PNMSTX+
white/orange
44—
55—
6 6 PNMSTX–
orange
77—
88—
1. The Cisco ONS 15454 ETSI is DCE.
Purpose This task installs alarm wires on the backplane so that you can provision
external (environmental) alarms and controls with the AIC or AIC-I card.
If you are using the AEP, do not perform this task.
Tools/Equipment Wire wrapper
#22 or #24 AWG (0.51 mm² or 0.64 mm²) wires
100-ohm shielded BITS clock cable pair #22 or #24 AWG (0.51 mm² or
0.64 mm²), twisted-pair T1-type
Prerequisite Procedures NTP-G5 Remove the Backplane Covers (ANSI Only), page 1-26
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
Table 1-5 LAN Pin Assignments (continued)
LAN RJ-45 Pin RJ-45 Pin Function
To Next Page
