Chapter 5 Provision Transponder and Muxponder Cards
DLP-G218 Change Section Trace Settings for the TXP_MR_10G and TXP_MR_10E Cards
Step 4 Click Apply.
Step 5 Return to your originating procedure (NTP).
Table 5-5 TXP_MR_10G and TXP_MR_10E Transponder Card Section Trace Settings
Parameter Description Options – ONS 15454 Options — ONS 15454 SDH
Port Sets the port number.
• 1-1 (OC192)
• 2—Trunk
• 1-1 (STM64)
• 2—Trunk
Trace Mode Sets the trace mode.
• Off/None
• Manual
• Off/None
• Manual
Section Trace
String Size
Sets the trace string size.
• 1 byte
• 16 byte
• 1 byte
• 16 byte
Transmit Displays the current
transmit string; sets a new
transmit string. You can
click the button on the right
to change the display. Its
title changes, based on the
current display mode. Click
Hex to change the display to
hexadecimal (button
changes to ASCII); click
ASCII to change the display
to ASCII (button changes to
Hex).
String of trace string size String of trace string size
Expected Displays the current
transmit string; sets a new
transmit string. You can
click the button on the right
to change the display. Its
title changes, based on the
current display mode. Click
Hex to change the display to
hexadecimal (button
changes to ASCII); click
ASCII to change the display
to ASCII (button changes to
Hex).
String of trace string size String of trace string size
Received (Display only) Displays the
current received string. You
can click Refresh to
manually refresh this
display, or check the
Auto-refresh every 5 sec
check box to keep this field
updated.
String of trace string size String of trace string size
