DLP-G221 Change OTN Settings for TXP_MR_10G and TXP_MR_10E Cards
Step 8 Return to your originating procedure (NTP).
DLP-G221 Change OTN Settings for TXP_MR_10G and TXP_MR_10E Cards
Step 1 In node view, double-click the TXP_MR_10G or TXP_MR_10E card where you want to change the OTN
settings.
Step 2 Click one of the Provisioning > OTN tabs, then click one of the following subtabs: OTN Lines,
G.709 Thresholds, FEC Thresholds, or Trail Trace Identifier.
Step 3 Modify any of the settings described in Tables 5-12 through 5-15.
Note You must modify Near End, and Far End independently; 15 Min and 1 Day independently; and
SM and PM independently. To do so, choose the appropriate radio button and click Refresh.
Table 5-12 describes the values on the Provisioning > OTN > OTN Lines tab.
Purpose This task changes the line optical transport network (OTN) settings for
TXP_MR_10G and TXP_MR_10E transponder cards.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Table 5-12 TXP_MR_10G and TXP_MR_10E Transponder Card OTN Lines Settings
Parameter Description Options
Port # (Display only) Port number. 2
G.709 OTN Sets the OTN lines according to
ITU-T G.709. Check box to enable.
• Enabled
• Disabled
FEC Sets the OTN lines forward error
correction (FEC) mode. FEC mode can be
Disabled, Enabled or Enhanced FEC
mode can be enabled (to provide greater
range and lower bit error rate).
• Enabled—(TXP_MR_10G only)
FEC is on.
• Disabled—FEC is off.
• Standard—(TXP_MR_10E only)
Standard FEC is on.
• Enhanced—(TXP_MR_10E only)
Enhanced FEC is on.
