Cisco ONS 15454 DWDM - DLP- G235 Change Card Settings for MXP_MR_2.5 G and MXPP_MR_2.5 G Cards

5-66
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 5 Provision Transponder and Muxponder Cards
DLP-G235 Change Card Settings for MXP_MR_2.5G and MXPP_MR_2.5G Cards
Stop. You have completed this procedure.
DLP-G235 Change Card Settings for MXP_MR_2.5G and MXPP_MR_2.5G Cards
Note Card settings can be changed only if the facilities are out of service (OOS).
Step 1 In node view, double-click the MXP_MR_2.5G or MXPP_MR_2.5G card where you want to change the
card settings.
Step 2 Click the Provisioning > Card tabs.
Step 3 Modify any of the settings described in Table 5-41.
Step 4 Click Apply.
Step 5 Return to your originating procedure (NTP).
Purpose This task changes the card settings for MXP_MR_2.5G and
MXPP_MR_2.5G muxponder cards.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Table 5-41 MXP_MR_2.5G and MXPP_MR_2.5G Muxponder Card Settings
Parameter Description Options
Card Mode Sets the mode of operation (option only
supported for SONET/SDH payloads).
Note This setting is not currently
supported. The only option
available currently is FC-GE.
• FC-GE
Wavelength Sets the wavelength of the DWDM side
optical transmitter.
• First Tunable Wavelength
• Further wavelengths in 100-GHz ITU
spacing
• Supported wavelengths are in white
and marked by asterisks (**);
unsupported wavelengths are gray.
Note The four available wavelengths
are listed in the Card Parameters
section of the window and also in
the Maintenance > Info tab.
