B-6
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
December 2006
Appendix B Hardware Specifications
B.2.2 Temperature
B.2.2 Temperature
Table B-2 provides temperature ranges and product names for ONS 15454 cards.
Note The I-Temp symbol is displayed on the faceplate of an I-Temp compliant card. A card without this
symbol is C-Temp compliant.
DWDM Cards
AD-1B-xx.x Nominal 17
Maximum 25
Nominal 0.35
Maximum 0.52
Nominal 58.0
Maximum 85.3
AD-4B-xx.x Nominal 17
Maximum 25
Nominal 0.35
Maximum 0.52
Nominal 58.0
Maximum 85.3
32WSS Nominal 50
Maximum 65
Nominal 1.04
Maximum 1.35
Nominal 170
Maximum 221
Transponder and
Muxponder
Cards
TXP_MR_10G 35.00
1
0.73 119.5
TXP_MR_10E Nominal 40
Maximum 50
Nominal 1.11
Maximum 1.04
Nominal 136.6
Maximum 170.7
TXP_MR_2.5G 35.00
1
0.73 119.5
TXPP_MR_2.5G 50
1
1.04 170.5
MXP_2.5G_10G 50
1
1.04 170.7
MXP_2.5G_10E Nominal 40
Maximum 50
Nominal 1.11
Maximum 1.04
Nominal 136.6
Maximum 170.7
MXP_MR_2.5G Nominal 50
Maximum 60
Nominal 1.04
Maximum 1.25
Nominal 170.7
Maximum 204
MXPP_MR_2.5G Nominal 50
Maximum 60
Nominal 1.04
Maximum 1.25
Nominal 170.7
Maximum 204
1. Calculated power; measured power was not available at the time of publication.
Table B-1 Individual Card Power Requirements (continued)
Card Type Card Name Watts Amperes at –48 V BTU/Hr.
Table B-2 Card Temperature Ranges and Product Names
Card Type Card Name
C-Temp Product Name
(32 to 131 degrees Fahrenheit,
0 to +55 degrees Celsius)
I-Temp Product Name
(–40 to 149 degrees Fahrenheit,
–40 to +65 degrees Celsius)
Common
Control Cards
TCC2/TCC2P — 15454-TCC2/TCC2P
AIC-I — 15454-AIC-I
AEP — 15454-AEP
MIC-A/P 15454-MIC-A/P —
MIC-C/T/P 15454 MIC-C/T/P —
