7-2
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 7 Create Channels and Circuits
NTP-G58 Locate and View Optical Channel Network Connections
NTP-G58 Locate and View Optical Channel Network
Connections
Step 1 Complete the “DLP-G46 Log into CTC” task on page 2-25 at a node on the network where you want to
view the circuits. If you are already logged in, continue with Step 2.
Note Do not check Disable Circuit Management in the Login dialog box. No circuits appear if this
option is checked.
Step 2 As needed, complete the “DLP-G100 Search for Optical Channel Network Connections” task on
page 7-2.
Step 3 As needed, complete the “DLP-G101 View Optical Channel Network Connection Information” task on
page 7-3.
Step 4 As needed, complete the “DLP-G102 Filter the Display of Optical Channel Network Connections” task
on page 7-7.
Step 5 As needed, complete the “DLP-G103 View Optical Channel Network Connections on a Span” task on
page 7-8.
Stop. You have completed this procedure.
DLP-G100 Search for Optical Channel Network Connections
Step 1 Navigate to the appropriate Cisco Transport Controller (CTC) view:
• To search the entire network, choose View > Go to Network View.
Purpose This procedure allows you to locate and view DWDM OCHNCs.
Tools/Equipment None
Prerequisite Procedures DLP-G105 Provision DWDM Optical Channel Network Connections,
page 7-10
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
Purpose This task searches for DWDM OCHNCs and ONS 15454 circuits at the
network, node, or card level.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
