DLP-G218 Change Section Trace Settings for the TXP_MR_10G and
TXP_MR_10E Cards
Note The Section Trace tab is available for the TXP_MR_10G and TXP_MR_10E cards only if no
PPM or an OC192 PPM has been provisioned. The tab is not available if a TEN_GE LAN Phy
or FC10G PPM has been provisioned.
Step 1 In node view, double-click the TXP_MR_10G or TXP_MR_10E card where you want to change the
section trace settings.
Step 2 Click the Provisioning > Line > Section Trace tabs.
Step 3 Modify any of the settings described in Table 5-5.
Wavelength Displays the wavelength of the
client port.
• First Tunable Wavelength
• Further wavelengths:
1310 nm to 1550 nm
100-GHz ITU spacing
Coarse wavelength division
multiplexing (CWDM)
spacing
• Supported wavelengths are
marked by asterisks (**)
• First Tunable Wavelength
• Further wavelengths:
1310 nm to 1550 nm
100-GHz ITU spacing
CWDM spacing
• Supported wavelengths are
marked by asterisks (**)
Reach Displays the optical reach distance
of the client port.
• The Reach options depend on
the traffic type that has been
selected
• The Reach options depend on
the traffic type that has been
selected
Purpose This task changes the section trace settings for the TXP_MR_10G and
TXP_MR_10E transponder cards.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
