D-70
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Appendix D Network Element Defaults
D.3.1 ETSI Card Default Settings
MXP-MR-2_5G.config.trunk.AlsRecoveryPulseDuration 4.0 (seconds) 2.0, 2.1, 2.2 .. 100.0 when
AlsMode is Disabled, Auto
Restart, Manual Restart
80.0, 80.1, 80.2 .. 100.0
when AlsMode is Manual
Restart for Test
MXP-MR-2_5G.config.trunk.AlsRecoveryPulseInterval 100 (seconds) 60–300
MXP-MR-2_5G.config.trunk.SDBER 1E-7 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
MXP-MR-2_5G.config.trunk.SendDoNotUse FALSE TRUE, FALSE
MXP-MR-2_5G.config.trunk.SFBER 1E-4 1E-3, 1E-4, 1E-5
MXP-MR-2_5G.config.trunk.SyncMsgIn TRUE FALSE, TRUE
MXP-MR-2_5G.opticalthresholds.client.alarm.HighLaserBias 90.0 (%) 0.0, 0.1, 0.2 .. 100.0
MXP-MR-2_5G.opticalthresholds.client.alarm.HighRxPower 3.0 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.client.alarm.HighTxPower 3.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.client.alarm.LowRxPower -21.0 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXP-MR-2_5G.opticalthresholds.client.alarm.LowTxPower -8.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXP-MR-2_5G.opticalthresholds.client.warning.15min.HighLaserBias 81.0 (%) 0.0, 0.1, 0.2 .. 100.0
MXP-MR-2_5G.opticalthresholds.client.warning.15min.HighRxPower 2.0 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.client.warning.15min.HighTxPower 2.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.client.warning.15min.LowRxPower -20.0 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXP-MR-2_5G.opticalthresholds.client.warning.15min.LowTxPower -7.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXP-MR-2_5G.opticalthresholds.client.warning.1day.HighLaserBias 85.5 (%) 0.0, 0.1, 0.2 .. 100.0
MXP-MR-2_5G.opticalthresholds.client.warning.1day.HighRxPower 2.5 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.client.warning.1day.HighTxPower 2.5 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.client.warning.1day.LowRxPower -20.5 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXP-MR-2_5G.opticalthresholds.client.warning.1day.LowTxPower -7.5 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXP-MR-2_5G.opticalthresholds.trunk.alarm.HighLaserBias 98.0 (%) 0.0, 0.1, 0.2 .. 100.0
MXP-MR-2_5G.opticalthresholds.trunk.alarm.HighRxPower -8.0 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
Table D-15 MXP_MR_2.5G Card Default Settings (ETSI) (continued)
Default Name Default Value Default Domain
