Appendix D Network Element Defaults
D.3.1 ETSI Card Default Settings
MXP-MR-2_5G.opticalthresholds.trunk.alarm.HighTxPower 30.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.trunk.alarm.LowRxPower -25.0 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXP-MR-2_5G.opticalthresholds.trunk.alarm.LowTxPower -40.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXP-MR-2_5G.opticalthresholds.trunk.warning.15min.HighLaserBias 95.0 (%) 0.0, 0.1, 0.2 .. 100.0
MXP-MR-2_5G.opticalthresholds.trunk.warning.15min.HighRxPower -7.5 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.trunk.warning.15min.HighTxPower 30.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.trunk.warning.15min.LowRxPower -24.5 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXP-MR-2_5G.opticalthresholds.trunk.warning.15min.LowTxPower -40.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXP-MR-2_5G.opticalthresholds.trunk.warning.1day.HighLaserBias 96.0 (%) 0.0, 0.1, 0.2 .. 100.0
MXP-MR-2_5G.opticalthresholds.trunk.warning.1day.HighRxPower -7.3 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.trunk.warning.1day.HighTxPower 30.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.trunk.warning.1day.LowRxPower -24.7 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXP-MR-2_5G.opticalthresholds.trunk.warning.1day.LowTxPower -40.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXP-MR-2_5G.pmthresholds.trunk.ms.farend.15min.BBE 21260 (count) 0–2212200
MXP-MR-2_5G.pmthresholds.trunk.ms.farend.15min.EB 21260 (count) 0–2212200
MXP-MR-2_5G.pmthresholds.trunk.ms.farend.15min.ES 87 (seconds) 0–900
MXP-MR-2_5G.pmthresholds.trunk.ms.farend.15min.SES 1 (seconds) 0–900
MXP-MR-2_5G.pmthresholds.trunk.ms.farend.15min.UAS 3 (seconds) 0–900
MXP-MR-2_5G.pmthresholds.trunk.ms.farend.1day.BBE 212600
(count)
0–2212200
MXP-MR-2_5G.pmthresholds.trunk.ms.farend.1day.EB 212600
(count)
0–212371200
MXP-MR-2_5G.pmthresholds.trunk.ms.farend.1day.ES 864 (seconds) 0–86400
MXP-MR-2_5G.pmthresholds.trunk.ms.farend.1day.SES 4 (seconds) 0–86400
MXP-MR-2_5G.pmthresholds.trunk.ms.farend.1day.UAS 10 (seconds) 0–86400
MXP-MR-2_5G.pmthresholds.trunk.ms.nearend.15min.BBE 21260 (count) 0–2212200
MXP-MR-2_5G.pmthresholds.trunk.ms.nearend.15min.EB 21260 (count) 0–2212200
MXP-MR-2_5G.pmthresholds.trunk.ms.nearend.15min.ES 87 (seconds) 0–900
MXP-MR-2_5G.pmthresholds.trunk.ms.nearend.15min.SES 1 (seconds) 0–900
Table D-15 MXP_MR_2.5G Card Default Settings (ETSI) (continued)
Default Name Default Value Default Domain
