Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 5 Provision Transponder and Muxponder Cards
DLP-G308 Provision the MXP_MR_2.5G and MXPP_MR_2.5G Client Port Alarm and TCA Thresholds
DLP-G308 Provision the MXP_MR_2.5G and MXPP_MR_2.5G Client Port Alarm
and TCA Thresholds
Step 1 In node view, double-click the MXP_MR_2.5G and MXPP_MR_2.5G card where you want to change
the client port alarm and TCA settings.
Step 2 Click the Provisioning > Optics Thresholds tabs. The TCA thresholds are shown by default.
Step 3 Referring to Table 5-48, provision the client port (Ports 1 through 8) TCA thresholds for RX Power
High, RX Power Low, TX Power High, and TX Power Low based on the client interface at the other end.
For additional information about client SFP and XFP interfaces, also known as PPMs, refer to
Appendix B, “Hardware Specifications.”
Note Do not modify the Laser Bias parameters.
Note You must modify 15 Min and 1 Day independently. To do so, choose the appropriate radio button
and click Refresh.
Step 4 Click Apply.
Purpose This task provisions the client port alarm and TCA thresholds for the
MXP_MR_2.5G and MXPP_MR_2.5G cards.
Tools/Equipment None
Prerequisite Procedures DLP-G278 Provision the Optical Line Rate, page 5-6
DLP-G46 Log into CTC, page 2-25
Required/As Needed Required
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Table 5-48 MXP_MR_2.5G and MXPP_MR_2.5G Card Client Interface TCA Thresholds
Port Type
(by CTC)
Pluggable Port
Module (XFP)
TCA RX
Power Low
TCA RX
Power High
TCA TX
Power Low
TCA TX
Power High
FC1G 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–17 0 –16 3
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–20 –3 –16 3
FC2G 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–15 0 –16 3
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–20 –3 –16 3
FICON1G 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–17 0 –16 3
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–20 –3 –16 3
