7-10
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 7 Create Channels and Circuits
DLP-G104 Assign a Name to a Port
DLP-G104 Assign a Name to a Port
Step 1 Double-click the card that has the port you want to provision. This can be any port on a traffic carrying
card.
Step 2 Click the Provisioning tab.
Step 3 Click the Port Name column for the port number to which you are assigning a name.
Step 4 Type the port name.
The port name can be up to 32 alphanumeric/special characters. The field is blank by default.
Step 5 Click Apply.
Step 6 Return to your originating procedure (NTP).
DLP-G105 Provision DWDM Optical Channel Network Connections
Step 1 Choose View > Go to Network View.
Step 2 Click the Circuits tab, then click Create.
Step 3 In the Circuit Creation dialog box, choose OCHNC from the Circuit Type list.
Step 4 Click Next.
Step 5 Define the circuit attributes:
• Name—Assign a name to the OCHNC. The name can be alphanumeric and up to 48 characters
(including spaces). Circuit names should be 44 characters or less if you want the ability to create
monitor circuits. If you leave the field blank, CTC assigns a default name to the circuit.
Purpose This task assigns a name to a port on any ONS 15454 card.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Purpose This task creates an OCHNC between ONS 15454s that are provisioned for
DWDM.
Tools/Equipment An OCHNC add port on the source node and an OCHNC drop port on
destination node of the same wavelength are required.
DLP-G46 Log into CTC, page 2-25
Prerequisite Procedures All procedures in Chapter 3, “Turn Up a Node” must be completed at all
nodes within the OCHNC route.
Required/As Needed As needed
Onsite/Remote Onsite
Security Level Provisioning or higher
