5-26
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 5 Provision Transponder and Muxponder Cards
DLP-G302 Provision the TXP_MR_10G and TXP_MR_10E Client Port Alarm and TCA Thresholds
Step 5 Under Types, click the Alarm radio button and click Refresh.
Step 6 Referring to Table 5-11, provision the Port 1 (Client) Alarm thresholds for RX Power High, RX Power
Low, TX Power High, and TX Power Low based on the client interface that is provisioned.
Note You must modify 15 Min and 1 Day independently. To do so, choose the appropriate radio button
and click Refresh.
Step 7 Click Apply.
Table 5-10 TXP_MR_10E and TXP_MR_10G Card Client Interface TCA Thresholds
Port Type
(by CTC)
Pluggable Port
Module (XFP)
TCA RX
Power Low
TCA RX
Power High
TCA TX
Power Low
TCA TX
Power High
SONET (or
SDH)
TXP_MR_10E uses
ONS-XC-10G-S1
TXP_MR_10G
(XFP not present)
–11 –1 –12 5
10G
Ethernet
LAN Phy
TXP_MR_10E uses
ONS-XC-10G-S1
TXP_MR_10G
(XFP not present)
–14 1 –12 5
10G
Ethernet
WA N P H Y
TXP_MR_10E uses
ONS-XC-10G-S1
TXP_MR_10G
(XFP not present)
–14 1 –12 5
Table 5-11 TXP_MR_10E and TXP_MR_10G Card Client Interface Alarm Thresholds
Port Type
(by CTC)
Pluggable Port
Module (XFP)
Alarm RX
Power Low
Alarm RX
Power High
Alarm TX
Power Low
Alarm TX
Power High
SONET (or
SDH)
TXP_MR_10E uses
ONS-XC-10G-S1
TXP_MR_10G
(XFP not present)
–14 2 –9 2
10G
Ethernet
LAN Phy
TXP_MR_10E uses
ONS-XC-10G-S1
TXP_MR_10G
(XFP not present)
–17 4 –9 2
10G
Ethernet
WA N P H Y
TXP_MR_10E uses
ONS-XC-10G-S1
TXP_MR_10G
(XFP not present)
–17 4 –9 2
