Chapter 5 Provision Transponder and Muxponder Cards
DLP-G223 Change Line Settings for MXP_2.5G_10G and MXP_2.5G_10E Cards
Service State Identifies the autonomously generated state that
gives the overall condition of the port. Service
states appear in the format: Primary State-Primary
State Qualifier, Secondary State. For more
information about service states, see Appendix C,
“DWDM Administrative and Service States.”
• IS-NR (ANSI) or Unlocked-enabled (ETSI)
• OOS-AU,AINS (ANSI) or Unlocked-disabled,
automaticInService (ETSI)
• OOS-MA,DSBLD (ANSI) or
Locked-enabled,disabled (ETSI)
• OOS-MA,MT (ANSI) or
Locked-enabled,maintenance (ETSI)
ALS Mode Sets the ALS function mode. The DWDM
transmitter supports ALS according to
ITU-T G.644 (06/99). ALS can be disabled or can
be set for one of three mode options.
• Disable (default): ALS is off; the laser is not
automatically shut down when traffic outages
(LOS) occur.
• Auto Restart: ALS is on; the laser automatically
shuts down when traffic outages (LOS) occur. It
automatically restarts when the conditions that
caused the outage are resolved.
• Manual Restart: ALS is on; the laser automatically
shuts down when traffic outages (LOS) occur.
However, the laser must be manually restarted
when conditions that caused the outage are
resolved.
• Manual Restart for Test: Manually restarts the
laser for testing.
SF BER Sets the signal fail bit error rate.
• 1E-3
• 1E-4
• 1E-5
SD BER Sets the signal degrade bit error rate.
• 1E-5
• 1E-6
• 1E-7
• 1E-8
• 1E-9
AINS Soak Sets the automatic in-service soak period.
Double-click the time and use the up and down
arrows to change settings.
• Duration of valid input signal, in hh.mm format,
after which the card becomes in service (IS)
automatically
• 0 to 48 hours, 15-minute increments
Type Sets the optical transport type.
• SONET
• SDH
ProvidesSync Sets the ProvidesSync card parameter. If checked,
the card is provisioned as an NE timing reference.
(This parameter does not appear for the
MXP_2.5G_10E trunk port.)
Checked or unchecked
Table 5-17 MXP_2.5G_10G or MXP_2.5G_10E Muxponder Card Line Settings (continued)
Parameter Description Options

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
