B-20
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
December 2006
Appendix B Hardware Specifications
B.4.9 4MD-xx.x Card Specifications
The 32DMX card has the following additional specifications:
• Environmental
–
Operating temperature:
C-Temp: –5 to +55 degrees Celsius (+23 to +131 degrees Fahrenheit)
–
Operating humidity: 5 to 95 percent RH
• Dimensions
–
Height: 12.65 in. (321.3 mm)
–
Width: 0.92 in. (23.4 mm)
–
Depth: 9.00 in. (228.6 mm)
B.4.9 4MD-xx.x Card Specifications
The 4MD-xx.x card optical specifications are listed in Table B-7.
Note For power specifications, see the “16.1.7 Multiplexer, Demultiplexer, and OADM Card Interface
Classes” section on page 16-6.
25 7 54.1 192.9 1554.13
26 54.9 192.8 1554.94
27 55.7 192.7 1555.75
28 56.5 192.6 1556.55
29 8 58.1 192.4 1558.17
30 58.9 192.3 1558.98
31 59.7 192.2 1559.79
32 60.6 192.1 1560.61
Table B-6 32DMX Channel Plan (continued)
Channel
Number Band Channel ID Frequency (GHz) Wavelength (nm)
