Table D-2 lists the MXP_2.5G_10G card default settings.
Table D-2 MXP_2.5G_10G Card Default Settings (ANSI)
Default Name Default Value Default Domain
MXP-2_5G-10G.config.client.AINSSoakTime 08:00
(hours:mins)
00:00, 00:15, 00:30 .. 48:00
MXP-2_5G-10G.config.client.AlsMode Disabled Disabled, Auto Restart, Manual
Restart, Manual Restart for Test
MXP-2_5G-10G.config.client.AlsRecoveryPulseDuration 4.0 (seconds)
• 2.0, 2.1, 2.2 .. 100.0 when
AlsMode is Disabled, Auto
Restart, Manual Restart
• 80.0, 80.1, 80.2 .. 100.0
when AlsMode is Manual
Restart for Test
MXP-2_5G-10G.config.client.AlsRecoveryPulseInterval 100 (seconds) 60–300
MXP-2_5G-10G.config.client.ppmPortAssignment OC48_PORT UNASSIGNED, OC48_PORT
MXP-2_5G-10G.config.client.ppmSlotAssignment UNASSIGNED UNASSIGNED, PPM (1 Port)
MXP-2_5G-10G.config.client.SDBER 1.00E-07 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
MXP-2_5G-10G.config.client.SendDoNotUse FALSE TRUE, FALSE
MXP-2_5G-10G.config.client.SFBER 1.00E-04 1E-3, 1E-4, 1E-5
MXP-2_5G-10G.config.client.SyncMsgIn TRUE FALSE, TRUE
MXP-2_5G-10G.config.client.TerminationMode Transparent Transparent, Line
MXP-2_5G-10G.config.trunk.AINSSoakTime 08:00
(hours:mins)
00:00, 00:15, 00:30 .. 48:00
MXP-2_5G-10G.config.trunk.AlsMode Disabled Disabled, Auto Restart, Manual
Restart, Manual Restart for Test
MXP-2_5G-10G.config.trunk.AlsRecoveryPulseDuration 4.0 (seconds)
• 2.0, 2.1, 2.2 .. 100.0 when
AlsMode is Disabled, Auto
Restart, Manual Restart
• 80.0, 80.1, 80.2 .. 100.0
when AlsMode is Manual
Restart for Test
MXP-2_5G-10G.config.trunk.AlsRecoveryPulseInterval 100 (seconds) 60–300
MXP-2_5G-10G.opticalthresholds.client.alarm.HighLaserBias 90.0 (%) 0.0, 0.1, 0.2 .. 100.0
MXP-2_5G-10G.opticalthresholds.client.alarm.HighRxPower 3.0 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXP-2_5G-10G.opticalthresholds.client.alarm.HighTxPower 3.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXP-2_5G-10G.opticalthresholds.client.alarm.LowRxPower -21.0 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
