B.6 SFP Specifications
– Nominal wavelength: 1310 nm
– Transmitter: DFB laser
• Receiver (client side)
– Maximum receiver level: –1 dBm at BER 1 * 10 exp – 12
– Minimum receiver level: –14 dBm at BER 1 * 10 exp – 12
– Receiver: APD
– Link loss budget: 8 dB minimum, at BER = 1 * 10 exp – 12
– Receiver input wavelength range: 1290 to 1605 nm
• Environmental
– Operating temperature: –5 to +55 degrees Celsius (+23 to +113 degrees Fahrenheit)
– Operating humidity: 5 to 95 percent, noncondensing
– Power consumption: 50.00 W (maximum), 1.11 A at –48 V, 136.6 BTU/hr
• Dimensions
– Height: 12.650 in. (321.3 mm)
– Width: 0.716 in. (18.2 mm)
– Depth: 9.000 in. (228.6 mm)
– Depth with backplane connector: 9.250 in. (235 mm)
– Weight not including clam shell: 3.1 lb (1.3 kg)
B.6 SFP Specifications
Table B-23 lists the specifications for available SFPs.
Table B-23 SFP Specifications
SFP Product ID Interface
Transmitter Output
Power Min/Max (dBm)
Receiver Input Power
Min/Max (dBm)
15454-SFP3-1-IR= OC-3 –15 to –8 –23 to –8
15454E-SFP-L.1.1= STM-1 –15 to –8 –34 to –10
15454-SFP12-4-IR= OC-12, D1 Video –15 to –8 –28 to –7
15454E-SFP-L.4.1= STM-4, D1 Video –15 to –8 –28 to –8
15454-SFP-OC48-IR= OC-48, DV6000 (C-Cor) –5 to +0 –18 to +0
ONS-SE-2G-S1= OC-48, STM-16 –10 to –3 –18 to –3
15454E-SFP-L.16.1= STM-16, DV6000
(C-Cor)
–5 to +0 –18 to 0
15454-SFP-200/
15454E-SFP-200
ESCON
1
–8 to –4 –28 to –3
15454-SFP-GEFC-SX=/
15454E-SFP-GEFC-S=
Fibre Channel
(1 and 2 Gbps), FICON
2
,
GE
–10 to –3.5 –17 to 0 (1FC and 1GE)
–15 to 0 (2FC)
