Appendix C DWDM Administrative and Service States
C.3 Service State Transitions
C.3 Service State Transitions
This section describes the transition from one service state to the next state for DWDM cards, optical
payload ports, OSC ports, OCHNCs, and transponder/muxponder cards and ports. A service state
transition is based on the action performed on the entity and any autonomous activity.
C.3.1 DWDM Card Service State Transitions
Table C-4 lists ANSI and ETSI service state transitions for AD-1B-xx.x, AD-4B-xx.x, AD-1C-xx.x,
AD-2C-xx.x, AD-4C-xx.x, OSC-CSM, OSCM, OPT-BST, OPT-PRE, 4MD-xx.x, 32WSS, 32MUX-O,
and 32DMX-O cards.
OOS,DSBLD Locked,disabled Removes the entity from service and disables it.
OOS,MT Locked,maintenance Removes the entity from service for maintenance.
Table C-3 ONS 15454 Administrative States (continued)
ANSI Administrative
State (PST,SST)
ETSI Administrative State
(PST,SST) Definition
Table C-4 ONS 15454 Optical Unit Service State Transitions
Current Service State Action Next Service State
IS-NR (ANSI)
Unlocked-enabled (ETSI)
Delete the card. OOS-AUMA,UAS (ANSI)
Locked-disabled,unassigned (ETSI)
Pull the card. OOS-AU,UEQ (ANSI)
Unlocked-disabled,notInstalled (ETSI)
Reset the card. OOS-AU,SWDL (ANSI)
Unlocked-disabled,softwareDownload (ETSI)
Alarm/condition is
raised.
OOS-AU,FLT (ANSI)
Unlocked-disabled,failed (ETSI)
OOS-AU,AINS & MEA (ANSI)
Unlocked-disabled,automaticInService &
mismatchOfEquipment (ETSI)
Pull the card. OOS-AU,AINS & UEQ (ANSI)
Unlocked-disabled,automaticInService &
notInstalled (ETSI)
Delete the card. If the card is valid:
• OOS-AUMA,UAS (ANSI)
• Locked-disabled,unassigned (ETSI)
If the card is invalid:
• OOS-AUMA,MEA & UAS (ANSI)
• Locked-disabled,mismatchOfEquipment &
unassigned (ETSI)
