5-74
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 5 Provision Transponder and Muxponder Cards
DLP-G240 Change MXP_MR_2.5G and MXPP_MR_2.5G Card Line Threshold Settings for SONET or SDH Payloads
Step 2 Click the Provisioning > Line > Section Trace tabs. Tabs and parameter selections vary according to
PPM provisioning.
Step 3 Modify any of the settings in the Section Trace tab as described in Tabl e 5-45 .
Step 4 Click Apply.
Step 5 Return to your originating procedure (NTP).
DLP-G240 Change MXP_MR_2.5G and MXPP_MR_2.5G Card Line Threshold
Settings for SONET or SDH Payloads
Table 5-45 MXP_MR_2.5G and MXPP_MR_2.5G Muxponder Card Line Section Trace Tab Settings
Parameter Description Options
Port (Display only) Port number. 9 (trunk for MXP_MR_2.5G) or 9 and 10
(trunks for MXPP_MR_2.5G)
Trace Mode Sets the trace mode.
• Off/None
• Manual
Section Trace
String Size
Sets the trace string size.
• 1 byte
• 16 byte
Transmit Displays the current transmit string; sets a new transmit string.
You can click the button on the right to change the display. Its title
changes, based on the current display mode. Click Hex to change
the display to hexadecimal (button changes to ASCII); click
ASCII to change the display to ASCII (button changes to Hex).
String of trace string size
Expected Displays the current expected string; sets a new expected string.
You can click the button on the right to change the display. Its title
changes, based on the current display mode. Click Hex to change
the display to hexadecimal (button changes to ASCII); click
ASCII to change the display to ASCII (button changes to Hex).
String of trace string size
Received (Display only) Displays the current received string. You can click
Refresh to manually refresh this display, or check the
Auto-refresh every 5 sec check box to keep this field updated.
String of trace string size
Purpose This task changes the line threshold settings for MXP_MR_2.5G and
MXPP_MR_2.5G muxponder cards for SONET or SDH payloads.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
