Chapter 11 Change DWDM Card Settings
DLP-G201 Change Optical Line Parameters for OSCM and OSC-CSM Cards
Admin State Sets the port service state unless network conditions
prevent the change. For more information about
administrative states, see Appendix C, “DWDM
Administrative and Service States.”
From the drop-down list, choose one of the
following:
• IS/Unlocked
• IS,AINS/Unlocked,automaticInService
• OOS,DSBLD/Locked,disabled
• OOS,MT/Locked,maintenance
Line Direction Provides the ability to associate a card with the line
direction. CTC automatically configures the line
direction during node setup. To change this setting,
you must change the Cisco MetroPlanner site plan
and import it to the node.
From the drop-down list, choose one of the
following:
• East to West
• West to East
Service State Identifies the autonomously generated state that
gives the overall condition of the port. Service states
appear in the format: Primary State-Primary State
Qualifier, Secondary State. For more information
about service states, see Appendix C, “DWDM
Administrative and Service States.”
• IS-NR/Unlocked-enabled
• OOS-AU,AINS/Unlocked-disabled,
automaticInService
• OOS-MA,DSBLD/Locked-enabled,disabled
• OOS-MA,MT/Locked-enabled,maintenance
Type (Display only) Identifies the type of port.
• Input Com
• Output Com
• Input Line
• Output Line
• Input OSC
• Output OSC
Power (Display only) Shows the current power level per
port.
—
VOA Mode (Display only) Shows the functional mode of the
variable optical attenuator (VOA), when present.
• Constant Attenuation
• Constant Power
VOA Power
Ref
(Display only) Shows the optical power setpoint that
must be reached when a VOA is present and VOA
Mode is set to Constant Power. This parameter can
only be modified by Automatic Node Setup (ANS).
—
VOA Power
Calib
Modifies the optical power value of the VOA when
VOA Mode is set to Constant Power.
Numeric. Double-click the parameter, enter a value,
and press Enter.
VOA
Attenuation
Ref
(Display only) Shows the VOA attenuation value
when VOA Mode is set to Constant Attenuation.
This parameter can only be modified by ANS.
—
VOA
Attenuation
Calib
Modifies the attenuation value of the VOA when the
VOA Mode is set to Constant Attenuation.
Numeric. Double-click the parameter, enter a value,
and press Enter.
Table 11-3 OSCM and OSC-CSM Card Optical Line Parameter Settings (continued)
Parameter Description Options
