Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 11 Change DWDM Card Settings
NTP-G101 Modify Alarm Interface Controller–International Settings
NTP-G101 Modify Alarm Interface Controller–International
Settings
Step 1 Complete the “DLP-G46 Log into CTC” task on page 2-25 at the node where you want to change the
AIC-I card settings. If you are already logged in, proceed to Step 2.
Step 2 Complete the “NTP-G103 Back Up the Database” procedure on page 13-2.
Step 3 Perform any of the following tasks as needed:
• DLP-G245 Change External Alarms Using the AIC-I Card, page 11-42
• DLP-G246 Change External Controls Using the AIC-I Card, page 11-43
• DLP-G247 Change AIC-I Card Orderwire Settings, page 11-44
Step 4 Complete the “NTP-G103 Back Up the Database” procedure on page 13-2.
Stop. You have completed this procedure.
DLP-G245 Change External Alarms Using the AIC-I Card
Note The procedure is the same if you are using the alarm expansion panel (AEP). In this case, the number of
contacts that are shown on the screen is changed accordingly.
Step 1 Confirm that external-device relays are wired to the ENVIR ALARMS IN pins. See the “DLP-G20
Install Alarm Wires on the MIC-A/P (ETSI Only)” task on page 1-48 (ETSI) or “DLP-G23 Install Alarm
Wires on the Backplane (ANSI Only)” task on page 1-53 (ANSI) for more information.
Purpose This procedure provisions the AIC-I card to receive input from or send
output to external devices wired to the backplane (called external alarms
and controls or environmental alarms), or changes orderwire settings.
Tools/Equipment None
Prerequisite Procedures NTP-G72 Provision External Alarms and Controls on the Alarm Interface
Controller-International Card, page 8-32
DLP-G109 Provision Orderwire, page 7-19
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Purpose This task changes external alarm settings on the AIC-I card.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
