B.4.8 32DMX Card Specifications
The 32DMX-O card has the following additional specifications:
• Environmental
– Operating temperature:
C-Temp: –5 to +55 degrees Celsius (+23 to +131 degrees Fahrenheit)
– Operating humidity: 5 to 95 percent RH
• Dimensions
– Height: 12.65 in. (321.3 mm)
– Width: 1.84 in. (46.8 mm)
– Depth: 9.00 in. (228.6 mm)
B.4.8 32DMX Card Specifications
The 32DMX card optical specifications are listed in Table B -5.
Note For power specifications, see the “16.1.7 Multiplexer, Demultiplexer, and OADM Card Interface
Classes” section on page 16-6.
Table B-4 32DMX-O Optical Specifications
Parameter Note Condition Min Max Unit
Rx filter shape
(–1 dB bandwidth)
All SOP and within
whole operating
temperature range
In 1/32—Out BOL +/–180 +/–300 pm
In 1/32—Out EOL +/–160 +/–300 pm
Insertion loss All SOP and within
whole operating
temperature range
In 1/32—Out BOL 4 8.0 dB
In 1/32—Out EOL 4 8.5 dB
VOA dynamic range — — 25 — dB
Maximum optical
input power
— — 300 — mW
Table B-5 32DMX Optical Specifications
Parameter Note Condition Min Typical Max Units
–1 dB
bandwidth
All SOP and within whole
operating temperature
range, connectors included,
and for maximum VOA
operating attenuation.
COM RX => TX 1, 32
(OUT)
+/–110 — — pm
–3 dB
bandwidth
+/–200 — — pm
Insertion loss All SOP, and within whole
operating temperature
range, connectors included.
COM RX => TX 1, 32 — — 5.5 dB
