3-11
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 3 Turn Up a Node
NTP-G26 Set Up CTC Network Access
NTP-G26 Set Up CTC Network Access
Step 1 Complete the “DLP-G46 Log into CTC” task on page 2-25. If you are already logged in, continue with
Step 2.
Step 2 Complete the “DLP-G56 Provision IP Settings” task on page 3-12 to provision the ONS 15454 IP
address, subnet mask, default router, DHCP server, IIOP listener port, and SOCKS proxy server settings.
Tip If you cannot log into the node, you can change its IP address, default router, and network mask
by using the LCD on the ONS 15454 fan-tray assembly (unless LCD provisioning is
suppressed). See the “DLP-G57 Set the IP Address, Default Router, and Network Mask Using
the LCD” task on page 3-15 for instructions. However, you cannot use the LCD to provision any
other network settings.
Step 3 If TCC2P cards are installed and you want to turn on the ONS 15454 secure mode, which allows two IP
addresses to be provisioned for the node, complete the “DLP-G264 Enable Node Security Mode” task
on page 3-17.
Note Secure mode is not available if TCC2 cards are installed.
Step 4 If static routes are needed, complete the “DLP-G58 Create a Static Route” task on page 3-18. For more
information about static routes, see Chapter 22, “Management Connectivity Reference.”
Step 5 If the ONS 15454 is connected to a LAN or WAN that uses OSPF and you want to share routing
information between the LAN/WAN and the ONS network, complete the “DLP-G59 Set Up or Change
Open Shortest Path First Protocol” task on page 3-19.
Step 6 If the ONS 15454 is connected to a LAN or WAN that uses RIP, complete the “DLP-G60 Set Up or
Change Routing Information Protocol” task on page 3-22.
Stop. You have completed this procedure.
Purpose This procedure provisions network access for a node, including its subnet
mask, default router, Dynamic Host Configuration Protocol (DHCP)
server, Internet Inter-Orb Protocol (IIOP) listener port, gateway settings,
static routes, Open Shortest Path First (OSPF) protocol, and Routing
Information Protocol (RIP).
Tools/Equipment None
Prerequisite Procedures NTP-G22 Verify Common Card Installation, page 3-4
Required/As Needed Required
Onsite/Remote Onsite or remote
Security Level Superuser
