Chapter 5 Provision Transponder and Muxponder Cards
DLP-G240 Change MXP_MR_2.5G and MXPP_MR_2.5G Card Line Threshold Settings for SONET or SDH Payloads
Step 1 In node view, double-click the MXP_MR_2.5G or MXPP_MR_2.5G card where you want to change the
line threshold settings.
Step 2 Click the Provisioning > Line Thresholds > SONET Thresholds (ANSI) or SDH Thresholds (ETSI)
tabs.
Step 3 Modify any of the settings as shown in Table 5-46.
Note You must modify Near End, and Far End independently; 15 Min and 1 Day independently; and
Line and Section independently. To do so, choose the appropriate radio button and click Refresh.
Table 5-46 MXP_MR_2.5G and MXPP_MR_2.5G Muxponder Card Line Threshold Settings
Field Description ONS 15454 Options ONS 15454 SDH Options
Port (Display only) Port
number.
• 9 (MXP_MR_2.5G)
• 9 and 10 (MXPP_MR_2.5G)
• 9 (MXP_MR_2.5G)
• 9 and 10 (MXPP_MR_2.5G)
CV Coding violations. Numeric. Threshold display options
include:
• Direction—Near End or Far End
• Interval—15 Min (minutes) or 1 day
• Types—Line or Section (near end
only)
Choose an option in each category and
click Refresh.
Numeric. Threshold display options
include:
• Direction—Near End or Far End
• Interval—15 Min (minutes) or 1 day
• Types—Multiplex Section or
Regeneration Section (near end only)
Choose an option in each category and
click Refresh.
ES Errored seconds. Numeric. Threshold display options
include:
• Direction—Near End or Far End
• Interval—15 Min (minutes) or 1 day
• Types—Line or Section (near end
only)
Choose an option in each category and
click Refresh.
Numeric. Threshold display options
include:
• Direction—Near End or Far End
• Interval—15 Min (minutes) or 1 day
• Types—Multiplex Section or
Regeneration Section (near end only)
Choose an option in each category and
click Refresh.
SES Severely errored
seconds.
Numeric. Threshold display options
include:
• Direction—Near End or Far End
• Interval—15 Min (minutes) or 1 day
• Types—Line or Section (near end
only)
Choose an option in each category and
click Refresh.
Numeric. Threshold display options
include:
• Direction—Near End or Far End
• Interval—15 Min (minutes) or 1 day
• Types—Multiplex Section or
Regeneration Section (near end only)
Choose an option in each category and
click Refresh.
