Chapter 7 Create Channels and Circuits
DLP-G103 View Optical Channel Network Connections on a Span
Note The following circuit types are not applicable to DWDM nodes: STS (displays only STS
circuits), VT (displays only VT circuits), VT Tunnel (displays only VT tunnels), STS-V
(displays STS VCAT circuits), VT-V (displays VT VCAT circuits), and VT Aggregation
Point (displays only VT aggregation points), VC_HO_PATH_CIRCUIT (displays VC4 and
VC4-Nc circuits), VC_LO_PATH_CIRCUIT (displays only VC3 and VC12 circuits),
VC_LO_PATH_TUNNEL (displays only low-order tunnels),
VC_LO_PATH_AGGREGATION (displays only log-order aggregation points),
VC_HO_PATH_VCAT_CIRCUIT (displays high-order VCAT circuits),
VC_LO_PATH_VCAT_CIRCUIT (displays low-order VCAT circuits).
• Size—Click the appropriate check boxes to filter circuits based on size: Multi-rate,
Equipment non specific, 2.5 Gbps FEC, 2.5 Gbps No FEC, 10 Gbps FEC, or 10 Gbps No FEC.
Note VT1.5, STS-1, STS3c, STS-6c, STS-9c, STS-12c, STS-24c, STS-48c, and STS-192c are not
applicable to ANSI DWDM nodes. VC12, VC3, VC4, VC4-2c, VC4-3c, VC4-4c, VC4-6c,
VC4-8c, VC4-9c, VC4-16c, and VC4-64 are not applicable to ETSI DWDM nodes.
The check boxes shown depend on the Type field selection. If you chose Any, all sizes are
available. If you chose OCHNC as the circuit type, only Multi-rate, Equipment non specific,
2.5 Gbps FEC, 2.5 Gbps No FEC, 10 Gbps FEC, and 10 Gbps No FEC appear.
Step 4 Click OK. Circuits matching the attributes in the Filter Circuits dialog box appear in the Circuits
window.
Step 5 To turn filtering off, click the Filter icon in the lower right corner of the Circuits window. Click the icon
again to turn filtering on, and click the Filter button to change the filter attributes.
Step 6 Return to your originating procedure (NTP).
DLP-G103 View Optical Channel Network Connections on a Span
Step 1 In node view, choose View > Go to Network View. If you are already in network view, continue with
Step 2.
Step 2 Right-click the green line containing the circuits you want to view and choose Circuits to view DWDM
OCHNCs or unprotected circuits on the span.
Purpose This task allows you to view OCHNCs and circuits on an ONS 15454 span.
Tools/Equipment None
Prerequisite Procedures DLP-G105 Provision DWDM Optical Channel Network Connections,
page 7-10
DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
