Chapter 5 Provision Transponder and Muxponder Cards
DLP-G308 Provision the MXP_MR_2.5G and MXPP_MR_2.5G Client Port Alarm and TCA Thresholds
Step 5 Repeat Steps 3 and 4 to provision each additional client port.
Step 6 Under Types, click the Alarm radio button and click Refresh.
Step 7 Referring to Table 5-49, provision the client port (Ports 1 through 8) Alarm thresholds for RX Power
High, RX Power Low, TX Power High, and TX Power Low based on the client interface that is
provisioned.
Note You must modify 15 Min and 1 Day independently. To do so, choose the appropriate radio button
and click Refresh.
FICON2G 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–17 0 –16 3
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–20 –3 –16 3
ONE_GE 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–17 0 –16 3
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–20 –3 –16 3
Table 5-48 MXP_MR_2.5G and MXPP_MR_2.5G Card Client Interface TCA Thresholds (continued)
Port Type
(by CTC)
Pluggable Port
Module (XFP)
TCA RX
Power Low
TCA RX
Power High
TCA TX
Power Low
TCA TX
Power High
Table 5-49 MXP_MR_2.5G and MXPP_MR_2.5G Card Client Interface Alarm Thresholds
Port Type
(by CTC)
Pluggable Port
Module (XFP)
Alarm RX
Power Low
Alarm RX
Power High
Alarm TX
Power Low
Alarm TX
Power High
FC1G 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–20 3 –13 –1
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–23 0 –13 0
FC2G 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–18 3 –13 –1
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–23 0 –13 0
FICON1G 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–20 3 –13 –1
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–23 0 –13 0
FICON2G 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–20 3 –13 –1
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–23 0 –13 0
