4-47
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 4 Perform Node Acceptance Tests
DLP-G87 Verify the AD-xB-xx.x Output Express Power
Step 13 Complete the “DLP-G83 Verify the OSC-CSM Power on OADM Nodes” task on page 4-43 for the
OSC-CSM card installed on the west side.
Step 14 Return to your originating procedure (NTP).
DLP-G87 Verify the AD-xB-xx.x Output Express Power
Step 1 Display the AD-xB-xx.x card in card view.
Step 2 Click the Provisioning > Optical Line > Parameters tabs.
Step 3 Change the Output Express port Admin State to OOS,MT (ANSI) or Locked,maintenance (ETSI).
Click Apply.
Step 4 Verify that the Output Express port Power value is greater than the default no-power value of –28 dBm.
Step 5 Return to your originating procedure (NTP).
DLP-G88 Verify the AD-xC-xx.x Output Express Power
Step 1 Display the AD-xC-xx.x card in card view.
Step 2 Click the Provisioning > Optical Line > Parameters tabs.
Step 3 Change the Output Express port Admin State to OOS,MT (ANSI) or Locked,maintenance (ETSI).
Click Apply.
Step 4 Verify that the Output Express port Power value is greater than the default no-power value of –30 dBm.
Step 5 Return to your originating procedure (NTP).
Purpose This task verifies the output express power of AD-xB-xx.x cards.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Superuser
Purpose This task verifies the output express power of the AD-xC-xx.x cards.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Superuser
