Appendix B Hardware Specifications
B.4.10 AD-1C-xx.x Card Specifications
The 4MD-xx.x card has the following additional specifications:
• Environmental
– Operating temperature:
C-Temp: –5 to +55 degrees Celsius (+23 to +131 degrees Fahrenheit)
– Operating humidity: 5 to 95 percent RH
• Dimensions
– Height: 12.65 in. (321.3 mm)
– Width: 0.92 in. (23.4 mm)
– Depth: 9.00 in. (228.6 mm)
B.4.10 AD-1C-xx.x Card Specifications
Table B-8 lists the AD-1C-xx.x optical specifications.
Table B-7 4MD-xx.x Optical Specifications
Parameter Note Condition Min Max Unit
Trx filter shape
(–0.5 dB bandwidth
TrxBW
2
)
All SOP and within
whole operating
temperature range
COM Rx—xx.xx Tx
COM Rx—yy.yy Tx
COM Rx—zz.zz Tx
COM Rx—kk.kk Tx
+/–180 — pm
xx.xx Rx—COM Tx
yy.yy Rx—COM Tx
zz.zz Rx—COM Tx
kk.kk Rx—COM Tx
Insertion loss
demultiplexer
section
All SOP and within
whole operating
temperature range
COM Rx—xx.xx Tx — 1.9 dB
COM Rx—yy.yy Tx — 2.4 dB
COM Rx—zz.zz Tx — 2.8 dB
COM Rx—kk.kk Tx — 3.3 dB
Insertion loss
multiplexer section
All SOP and within
whole operating
temperature range
(two connectors
included)
xx.xx Rx—COM Tx — 3.6 dB
yy.yy Rx—COM Tx — 3.2 dB
zz.zz Rx—COM Tx — 3.0 dB
kk.kk Rx—COM Tx — 2.6 dB
VOA dynamic range — — 25 — dB
Maximum optical
input power
— — 300 — mW
