Chapter 5 Provision Transponder and Muxponder Cards
DLP-G221 Change OTN Settings for TXP_MR_10G and TXP_MR_10E Cards
Step 4 Click Apply.
Step 5 Return to your originating procedure (NTP).
Table 5-15 TXP_MR_10G and TXP_MR_10E Transponder Card Trail Trace Identifier Settings
Parameter Description Options
Port Sets the port number.
• 1
• 2
Level Sets the level.
• Section
• Path
Trace Mode Sets the trace mode.
• Off/None
• Auto
• Manual
Transmit Displays the current transmit string; sets
a new transmit string. You can click the
button on the right to change the display.
Its title changes, based on the current
display mode. Click Hex to change the
display to hexadecimal (button changes to
ASCII); click ASCII to change the
display to ASCII (button changes to Hex).
String of trace string size;
trail trace identifier is 64 bytes in length.
Expected Displays the current expected string; sets
a new expected string. You can click the
button on the right to change the display.
Its title changes, based on the current
display mode. Click Hex to change the
display to hexadecimal (button changes to
ASCII); click ASCII to change the
display to ASCII (button changes to Hex).
String of trace string size
Received (Display only) Displays the current
received string. You can click Refresh to
manually refresh this display, or check
the Auto-refresh every 5 sec check box to
keep this field updated.
String of trace string size
