10-31
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 10 Manage the Node
DLP-G174 Switch Between TDM and DWDM Network Views
DLP-G174 Switch Between TDM and DWDM Network Views
Step 1 From the View menu, choose Go to Network View.
Step 2 From the Network Scope drop-down list on the toolbar, choose one of the following:
• All—Displays both TDM and DWDM nodes.
• TDM—Displays only ONS 15454s with SONET or SDH cards including the transponder and
muxponder cards.
• DWDM—Displays only ONS 15454s with DWDM cards, including the transponder and muxponder
cards.
Step 3 Return to your originating procedure (NTP).
NTP-G83 Modify or Delete Card Protection Settings
Caution Modifying and deleting protection groups can be service affecting.
Step 1 Complete the “DLP-G46 Log into CTC” task on page 2-25. If you are already logged in, continue with
Step 2.
Step 2 Perform any of the following tasks as needed:
• DLP-G175 Modify a Y-Cable Protection Group, page 10-32
• DLP-G176 Modify a Splitter Protection Group, page 10-33
• DLP-G177 Delete a Y-Cable Protection Group, page 10-33
Step 3 Complete the “NTP-G103 Back Up the Database” procedure on page 13-2.
Purpose Use this task to switch between time division multiplexing (TDM) and
DWDM network views.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
Purpose This procedure modifies and deletes card protection settings.
Tools/Equipment None
Prerequisite Procedures NTP-G33 Create a Y-Cable Protection Group, page 5-10
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
