Cisco ONS 15454 DWDM - DLP- G268 Provision TXP_MR_2.5 G Cards for Acceptance Testing

4-4
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 4 Perform Node Acceptance Tests
DLP-G268 Provision TXP_MR_2.5G Cards for Acceptance Testing
DLP-G268 Provision TXP_MR_2.5G Cards for Acceptance Testing
Step 1 If you have installed and verified the TXP_MR_2.5G cards, continue with Step 3. If you have not
installed the TXP cards, verify that you have TXP_MR_2.5G cards for every wavelength that you will
test. Table 4-1 lists the TXP_MR_2.5G part numbers and wavelengths.
Step 2 Install each TXP card using the “NTP-G32 Install the Transponder and Muxponder Cards” procedure on
page 3-43. If there are not enough open slots to install all the cards at one time, you can perform the
acceptance tests one TXP at a time. However, you will need to uninstall and install the TXP cards for
the wavelengths being tested.
Step 3 Display the TXP_MR_2.5G for the first wavelength you are testing (see Table 4-1) in card view.
Step 4 Click the Provisioning > Line > [Service Type] tabs.
Step 5 Click the Admin State column for the trunk port and choose OOS,Disable (ANSI) or Unlocked,disable
(ETSI) from the drop-down list.
Step 6 Click Apply, then click Yes .
Step 7 Click the Provisioning > Card tabs.
Step 8 In the Wavelength field, choose the first wavelength required by the acceptance test.
Step 9 Click Apply.
Step 10 Click the Provisioning > Line > [Service Type] tabs.
Purpose This procedure provisions a TXP_MR_2.5G card for acceptance testing
when a tunable laser is not available.
Tools/Equipment Eight TXP_MR_2.5G cards covering the 32 C-band wavelengths (see
Table 4 -1)
Prerequisite Procedures NTP-G32 Install the Transponder and Muxponder Cards, page 3-43
NTP-G34 Install Fiber-Optic Cables on DWDM Cards and DCUs, page
3-48
Required/As Needed As needed
Onsite/Remote Onsite
Security Level Superuser
Table 4-1 TXP_MR_2.5G Card Wavelengths and Part Numbers
Part Number Wavelengths
15454-MR-L1-30.3 1530.33–1532.68
15454-MR-L1-34.2 1534.25–536.61
15454-MR-L1-38.1 1538.19–1540.56
15454-MR-L1-42.1 1542.14–1544.53
15454-MR-L1-46.1 1546.12–1548.51
15454-MR-L1-50.1 1550.12–1552.52
15454-MR-L1-54.1 1554.13–1556.55
15454-MR-L1-58.1 1558.17–1560.61
