3-18
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 3 Turn Up a Node
DLP-G58 Create a Static Route
Note The SOCKS proxy server is automatically enabled when you enable secure mode.
Step 9 Click Finish.
Within the next 30 to 40 seconds, the TCC2Ps reboot. CTC switches to network view, and the CTC
Alerts dialog box appears. In network view, the node changes to grey and a DISCONNECTED condition
appears.
Step 10 In the CTC Alerts dialog box, click Close. Wait for the reboot to finish. (This might take several
minutes.)
Step 11 After the DISCONNECTED condition clears, complete the following steps to suppress the backplane IP
address from display in CTC and the LCD. If you do not want to suppress the backplane IP address
display, continue with Step 12.
a. Display the node in node view.
b. Click the Provisioning > Security > Data Comm tabs.
c. In the LCD IP Setting field, choose Suppress Display. This removes the IP address from display on
the ONS 15454 LCD.
d. Check the Suppress CTC IP Address check box. This removes the IP address from display in the
CTC information area and from the Provisioning > Security > Data Comm tab.
e. Click Apply.
Note After you turn on secure mode, the TCC2P IP address becomes the node IP address.
Step 12 Return to your originating procedure (NTP).
DLP-G58 Create a Static Route
Purpose This task creates a static route to establish CTC connectivity to a computer
on another network. This task is performed when one of the following
conditions exists:
• CTC computers on one subnet need to connect to ONS 15454 nodes
that are connected by a router to ONS 15454 nodes residing on another
subnet. OSPF is not enabled and the External Network Element
gateway setting is not checked.
• You need to enable multiple CTC sessions among ONS 15454 nodes
residing on the same subnet and the External Network Element
gateway setting is not enabled.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed.
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
