Chapter 5 Provision Transponder and Muxponder Cards
DLP-G228 Change Line OTN Settings for MXP_2.5G_10G and MXP_2.5G_10E Cards
Table 5-26 describes the values on the Provisioning > OTN > OTN G.709 Thresholds tab.
Table 5-25 MXP_2.5G_10G and MXP_2.5G_10E Muxponder Card Line OTN Settings
Parameter Description Options
Port # (Display only) Displays the port number. 5
G.709 OTN Sets the OTN lines according to
ITU-T G.709.
• Enabled
• Disabled
FEC Sets the OTN line FEC mode. FEC mode
can be Disabled or Enabled. Enhanced
FEC mode can be enabled (to provide
greater range and lower bit error rate).
E-FEC applies only to the
MXP_2.5G_10E card.
• Enabled—(MXP_2.5G_10G only)
FEC is on
• Disabled—FEC is off
• Standard—(MXP_2.5G_10E only)
FEC is on
• Enhanced—(MXP_2.5G_10E only)
Enhanced FEC is on
SF BER Sets the signal fail bit error rate.
• 1E-5
SD BER Sets the signal degrade bit error rate.
• 1E-5
• 1E-6
• 1E-7
• 1E-8
• 1E-9
Asynch/Synch
Mapping
(MXP_2.5G_10E only) The
MXP_2.5G_10E can perform standard
ODU multiplexing according to
ITU-T G.709. The card uses this to
aggregate the four OC-48 client signals.
• ODU Multiplex
Table 5-26 MXP_2.5G_10G and MXP_2.5G_10E Muxponder Card ITU-T G.709 Threshold Settings
Parameter Description Options
Port (Display only) Port number 5
ES Errored seconds Numeric. Can be set for Near End or Far
End, for 15-minute or one-day intervals,
or for SM (OTUk) or PM (ODUk). Select
a bullet and click Refresh.
SES Severely errored seconds. Two types of
thresholds can be asserted. Selecting the
SM (OTUk) radio button selects FEC,
overhead management, and PM using
OTUk. Selecting the PM radio button
selects path PM using ODUk.
Numeric. Can be set for Near End or Far
End, for 15-minute or one-day intervals,
or for SM (OTUk) or PM (ODUk). Select
a bullet and click Refresh.
UAS Unavailable seconds Numeric. Can be set for Near End or Far
End, for 15-minute or one-day intervals,
or for SM (OTUk) or PM (ODUk). Select
a bullet and click Refresh.
