3-84
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 3 Turn Up a Node
NTP-G38 Provision OSC Terminations
• Fail - Out of Range—The calculated setpoint is outside the expected range. Repeat the “NTP-G36
Calculate Cable Connections” procedure on page 3-80 to verify that all connections were
provisioned correctly, paying attention to connections that require manual provisioning.
Note The Fail - Out of Range condition must be cleared before proceeding. Contact your next
level of support if you are unable to clear this status.
• Fail - Port in IS State—The parameter could not be calculated because the port is in service. This
status should normally not appear at this point in node turn-up. If it does, display the card in card
view, change the port administrative state to OOS,DSLB (ANSI) or Locked,disabled (ETSI), and
repeat Steps 6 through 11.
Stop. You have completed this procedure.
NTP-G38 Provision OSC Terminations
Step 1 Complete the “DLP-G46 Log into CTC” task on page 2-25 at the node where you want to provision the
OSC terminations. If you are already logged in, continue with Step 2.
Step 2 In node view, click the Provisioning > Comm Channels > OSC tabs.
Step 3 In the OSC Terminations area, click Create (Figure 3-22).
Purpose This procedure provisions the OSC terminations.
Tools/Equipment None
Prerequisite Procedures NTP-G138 Import a Cisco MetroPlanner Configuration File, page 3-82
Required/As Needed Required
Onsite/Remote Onsite or remote
Security Level Superuser
