Cisco ONS 15454 DWDM - Figure; Table 2-1 CTC Computer Setup for Local Craft Connections to the ONS 15454

2-10
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 2 Connect the PC and Log into the GUI
NTP-G18 Set Up CTC Computer for Local Craft Connection to the ONS 15454
Step 2 Connect a straight-through CAT-5 LAN cable from the PC or Solaris workstation NIC to one of the
following:
• RJ-45 (LAN) port on the active or standby TCC2/TCC2P card
• RJ-45 (LAN) port on a hub or switch to which the ONS 15454 is physically connected
Note For instructions on crimping your own straight-through (CAT-5) LAN cables, refer to the
Cisco ONS 15454 Troubleshooting Guide or the Cisco ONS 15454 SDH Troubleshooting
Guide.
Note For initial shelf turn-up, you should connect your PC directly to the LAN port on the
TCC2/TCC2P card of the ONS 15454.
Step 3 After setting up your CTC computer, continue with the “NTP-G21 Log into the ONS 15454 GUI”
procedure on page 2-24 as needed.
Stop. You have completed this procedure.
• You are connecting from a Windows PC.
• All nodes that you will access run software
Release 3.3 or later.
• You will connect to ONS 15454s at different
locations and times and do not wish to reconfigure
your PC’s IP settings each time.
• You will not access or use non-ONS 15454
applications such as ping and tracert (trace route).
• If you are using an ANSI shelf, you will connect to
the TCC2/TCC2P Ethernet port or backplane LAN
pins either directly or through a hub.
• If you are using an ETSI shelf, you will connect to
the ONS 15454 Ethernet port or the RJ-45 jack on
the MIC-C/T/P FMEC either directly or through a
hub.
DLP-G41 Set Up a Windows PC for Craft
Connection to an ONS 15454 Using
Automatic Host Detection, page 2-16
• You are connecting from a Solaris workstation.
• You will connect to one ONS 15454.
• You need to access non-ONS 15454 applications
such as ping and tracert (trace route).
DLP-G42 Set Up a Solaris Workstation for a
Craft Connection to an ONS 15454, page
2-19
Table 2-1 CTC Computer Setup for Local Craft Connections to the ONS 15454 (continued)
CTC Connection Environment CTC Computer Setup Task (continued)
