Appendix D Network Element Defaults
D.2.1 ANSI Card Default Settings
• FEC Thresholds—TXP and MXP cards. Sets the performance monitoring (PM) parameters for
gathering FEC performance data and detecting problems early.
• Optical Thresholds—TXP and MXP cards. Sets the PM parameters for gathering physical optics
performance data and detecting problems early.
• OTN Thresholds—TXP and MXP cards. Sets the PM parameters for gathering OTN trunk-side
performance data and detecting problems early.
• PM Threshold settings—All cards. Sets the PM parameters for gathering performance data and
detecting problems early.
Note For more information about each individual card setting, see Chapter 5, “Provision Transponder and
Muxponder Cards.”
Note For more information about the PM parameters, see Chapter 9, “Monitor Performance.”
D.2.1.1 MXP_2.5G_10E Card Default Settings
Table D-1 lists the MXP_2.5G_10E card default settings.
Table D-1 MXP_2.5G_10E Card Default Settings (ANSI)
Default Name Default Value Default Domain
MXP-2_5G-10E.config.client.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
MXP-2_5G-10E.config.client.AisSquelchMode Squelch Ais, Squelch
MXP-2_5G-10E.config.client.AlsMode Disabled Disabled, Auto Restart, Manual
Restart, Manual Restart for Test
MXP-2_5G-10E.config.client.AlsRecoveryPulseDuration 2.0 (seconds)
• 2.0, 2.1, 2.2 .. 100.0 when
AlsMode is Disabled, Auto
Restart, Manual Restart
• 80.0, 80.1, 80.2 .. 100.0
when AlsMode is Manual
Restart for Test
MXP-2_5G-10E.config.client.AlsRecoveryPulseInterval 100 (seconds) 100–2000
MXP-2_5G-10E.config.client.ppmPortAssignment OC48_PORT UNASSIGNED, OC48_PORT
MXP-2_5G-10E.config.client.ppmSlotAssignment UNASSIGNED UNASSIGNED, PPM (1 Port)
MXP-2_5G-10E.config.client.SDBER 1.00E-07 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
MXP-2_5G-10E.config.client.SendDoNotUse FALSE TRUE, FALSE
MXP-2_5G-10E.config.client.SFBER 1.00E-04 1E-3, 1E-4, 1E-5
MXP-2_5G-10E.config.client.SyncMsgIn TRUE FALSE, TRUE
MXP-2_5G-10E.config.client.TerminationMode Transparent Transparent, Section
MXP-2_5G-10E.config.trunk.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
MXP-2_5G-10E.config.trunk.AlsMode Disabled Disabled, Auto Restart, Manual
Restart, Manual Restart for Test
